Rotary Broaches
Slater Tools Inc. offers the largest variety of internal and external rotary broaches, also known as wobble broaches. Fast delivery is guaranteed on all polygon forms, with standard square and hex broaches available from stock. Custom cut lengths and overall lengths, including 28mm, are available. Rotary broaches can be produced from hardened high speed M2 steel, PM4 or T15 cobalt. Tough applications on CNC and screw machines may be improved using coatings such as TiN, TiCN, and TiALN, available for all rotary broaches. Special forms include double D, involutes, keyways, serrations, six lobes (hexalobular/ torx-style), splines and more! Vent holes, quantity discounts and resharpening are offered on all Rotary Broaches.
|
|
|
|
- Available Coatings: TiN, TiCN, TiAN
- Available Materials: M2 Tool Steel, PM4 HSS, T15
- Custom Overall Lengths Available (including 28mm)
- Custom Cut Lengths Available
- Special across-the-flat dimensions
- MICRO forms
- Corner radius and Spun Ground Diameter
- Single or Double Vent Holes
- Resharpening Offered
- Quantity Discounts
|
|
- Available Coatings: TiN, TiCN, TiAN
- Available Materials: M2 Tool Steel, PM4 HSS, T15
- Custom Overall Lengths Available
- Special across-the-flat dimensions
- Resharpening Offered
- Quantity Discounts
|
|
- Made per customer print
- Available Coatings: TiN, TiCN, TiAN
- Available Materials: M2 Tool Steel, PM4 HSS, T15
- Custom Overall Lengths Available
- Custom Cut Lengths Available
- Single or Double Vent Holes
- Special tolerances
- Resharpening Offered
- Quantity Discounts
|
|
|
|
|
|
Rotary Broach Tool Holders
Rotary or wobble broaching is an exclusive, fast and accurate method of producing hex, square, serration or other forms. The polygon form is created while either the machine spindle or the tool holder body is rotating. The Rotary Broaching Tool Holder can be used on any CNC, Swiss, screw, milling or other turning machine. Slater Tools offers different varieties and sizes of Rotary Broaching Tool Holders to meet all of your tooling requirements.
|
|
|
|
- 4 design offerings for optimum application fit
- Broach form size capacity range: .028-.750
- No Center Indicating Required
- No Set-Up Time
- Industry Best Tool Clearance
- No need to alter tool holder shank length
- Ideal For Swiss and precision machines
- Different shank sizes available
|
|
- 4 design offerings for optimum application fit
- Broach form size capacity range: .028-1.135
- Different shank sizes available
- Straight Shank or Morse Taper Offered
- Accepts any overall length broach
- Can be used on any CNC, lathe, mill, Swiss, screw or other turning machine
|
|
- 5 design offerings for optimum application fit
- Broach form size capacity range: .125-1.50
- Different shank sizes available
- Accepts any overall length broach
- Straight shank and Morse taper offered
- Can be used on any CNC, lathe, mill, Swiss screw or other turning machine
|
|
|
|
|
|
